The Motorola APX 6000XE BN M3.5 UHF Range 1 is a rugged P25 portable radio with 380–470 MHz coverage, up to 1,000 channels, GPS, Bluetooth, advanced audio and IP68 protection.
Motorola APX 6000XE BN M3.5 UHF Range 1 P25 Portable Two-Way Radio
The Motorola APX 6000XE BN M3.5 UHF Range 1 is a rugged professional P25 portable two-way radio designed for demanding communication environments. Built for firefighters, EMS personnel, law enforcement, public safety agencies, government organizations and other professional users, this Motorola APX 6000XE combines dependable P25 digital communications with advanced audio, rugged construction and professional-grade controls.
The Motorola APX 6000XE BN M3.5 UHF Range 1 operates across the 380–470 MHz UHF Range 1 band. The M3.5 configuration provides a full-color display, backlit keypad, advanced controls and capacity for up to 1,000 channels. Motorola documentation identifies the UHF Range 1 M3.5 BN model as H98QDH9PW7BN.
Motorola APX 6000XE BN M3.5 UHF Range 1 P25 Communications
Designed for compatible professional radio systems, the Motorola APX 6000XE BN M3.5 UHF Range 1 supports APCO P25 Phase 1 FDMA and Phase 2 TDMA digital communications.
The APX 6000XE platform supports conventional and trunked operation, including compatible ASTRO 25, SmartNet and SmartZone systems. Actual functionality depends on the radio’s software, programming and installed feature options.
With 380–470 MHz coverage, this UHF Range 1 radio is designed for organizations operating compatible UHF P25 communication infrastructure.
M3.5 Display and Keypad
The M3.5 configuration provides an advanced user interface designed for professional users who need access to multiple channels, talkgroups and radio functions.
Key interface features include:
Full bitmap color LCD display
Four lines of text
Two lines of icons
Backlit 4 × 3 keypad
Three soft keys
Four-direction navigation key
Home and Data buttons
Up to 1,000 channels
Three programmable side buttons
Large push-to-talk button
Orange emergency button
This combination provides convenient access to communication channels and frequently used radio functions, including when operating in demanding field conditions.
Rugged APX Extreme Design
The Motorola APX 6000XE BN M3.5 UHF Range 1 is part of Motorola’s APX Extreme Series, designed for users who need a radio capable of handling challenging working environments.
Its distinctive T-shaped design provides a secure grip, while large controls are designed to remain accessible when users are wearing gloves. The radio incorporates a rugged aluminum-alloy endoskeleton and, on the enhanced platform, IP68 protection.
Motorola specifies IP68 protection for the enhanced APX 6000XE platform, including resistance to water submersion under specified test conditions.
Advanced Audio for Noisy Environments
Clear communications can be critical in emergency and industrial environments. The APX 6000XE incorporates Motorola audio technologies designed to improve voice communication in demanding conditions.
The platform includes dual microphones and an Extreme Audio profile. Depending on configuration, enhanced audio capabilities can include noise suppression, adaptive gain control, speaker equalization and windporting.
These features can be particularly useful for firefighters, emergency responders, transportation personnel and industrial workers operating around machinery, vehicles, alarms and other sources of background noise.
Motorola APX 6000XE BN M3.5 UHF Range 1 Specifications
Specification
Details
Brand
Motorola
Radio
APX 6000XE
Configuration
M3.5 BN
Band
UHF Range 1
Frequency Range
380–470 MHz
Model Number
H98QDH9PW7BN
Channel Capacity
Up to 1,000 channels
Digital Technology
APCO P25 Phase 1 FDMA / Phase 2 TDMA
Channel Spacing
25 / 20 / 12.5 kHz
RF Output
1–5 W adjustable, depending on configuration
Display
Full-color LCD
Keypad
Backlit 4 × 3 keypad
GPS
GPS/GLONASS, depending on configuration
Bluetooth
Mission Critical Wireless Bluetooth
Protection
IP68 on enhanced platform
Battery
Motorola IMPRES 2 Li-Ion options
Motorola documentation specifies 380–470 MHz UHF Range 1 coverage and adjustable RF output of 1–5 W for the enhanced platform.
GPS, Bluetooth and Professional Connectivity
Depending on the individual radio configuration, the Motorola APX 6000XE BN M3.5 UHF Range 1 can support several professional connectivity and location features, including:
Integrated GPS/GLONASS
Mission Critical Wireless Bluetooth
ASTRO 25 Integrated Voice & Data
Voice announcements
Intelligent lighting
Radio profiles
Text messaging
Programming Over Project 25
Over-the-air rekeying
P25 authentication
Optional Wi-Fi on supported configurations
These capabilities can help integrate the radio into larger professional communication networks.
Security and Encryption
The APX 6000XE platform supports professional communications security features. Depending on the individual radio’s installed options and configuration, encryption capabilities may include AES, DES, DES-XL, DES-OFB and ADP.
For used equipment, buyers should verify the radio’s actual installed encryption features, software configuration and key-management capabilities. Encryption support should not be assumed solely from the APX 6000XE model name.
Applications
The Motorola APX 6000XE BN M3.5 UHF Range 1 is suitable for organizations operating compatible UHF P25 systems, including:
Fire departments
Police and law enforcement
EMS and emergency services
Public safety agencies
Government organizations
Security teams
Utilities
Transportation
Industrial operations
Critical infrastructure
Search and rescue
Its rugged construction, glove-friendly controls and advanced audio make it particularly suitable for demanding professional environments.
Programming and Compatibility
Before purchasing a Motorola APX 6000XE UHF Range 1, customers should verify compatibility with their existing communication system.
Individual APX radios can differ in:
Frequency configuration
Software version
Flashcode
Feature entitlements
Encryption options
Talkgroups
Trunking capabilities
Firmware
Programming
The radio may require professional programming before it can operate on a specific P25 system. Customers should verify required frequencies, talkgroups, system type and feature requirements with their radio administrator or qualified radio technician.
For used radios, it is also recommended to confirm the exact model number, physical condition, battery condition, accessories and installed features before deployment.
Why Choose the Motorola APX 6000XE BN M3.5 UHF Range 1?
If you’re looking for a Motorola APX 6000XE BN M3.5 UHF Range 1 P25 portable radio, this configuration offers an impressive combination of rugged construction, professional P25 technology, advanced audio and an easy-to-use color display and keypad.
With 380–470 MHz UHF Range 1 coverage, up to 1,000 channels, P25 Phase 1/2, GPS/GLONASS, Bluetooth and rugged IP68 protection, it is a strong choice for compatible professional and public-safety communication systems.
The H98QDH9PW7BN model number makes this radio particularly useful for buyers searching for a specific APX 6000XE configuration.
Important: Features, software, encryption, programming, accessories and system compatibility vary by individual radio configuration. Always verify the specific unit before purchase and deployment.
